Technical specifications

• Excavator size: 28 – 38 Ton.
• Weight (top plate not included): 5,540 kg
• Operating pressure: 25 MPa
• Maximum operation flow: 210 L/min
• Hydraulic circuit: Shear mode
• Loading capacity: 1.2 m³
• External width: 1,280 mm
• Internal width: 1,100 mm
• Length: 2,620 mm
• Height: 1,360 mm
• Crushing cam opening: h 440 mm
• Output size regulation: 0 – 16 to 0 – 250 mm
