Heizohack HM 10-500 KF
Heizohack HM 10-500 KF
Heizohack HM 10-500 KF

These wood chippers are the entry-level Heizohack machines in the professional chipping sector. With a trailing axle and no loading crane, these drum chippers are ideally suited for feeding with an excavator or loading crane located on the tractor. The extremely large top roller ensures reliable in-feed even with very bulky material.

More information:

  • Flexible area of use
  • Up to 80 cm in-feed height
  • Up to 121 cm in-feed width
  • Driven by propshaft
  • Upstream tray in-feed roller
  • Chassis with trailing axle
  • Control: automatic load-dependent feed control, with integrated cycle control
  • Propulsion: it is done via cardan shaft and V-belt drive
  • Factory crane design: With Palfinger Epsilon C60F86 or M70F101 type crane, optional Heizogreif energy bucket.

Intake

  • Conveyor belt: 900 mm
  • Pressure roller, diameter: 800 mm
  • Infeed table length: 1500 mm

Technical data

Infeed height 800 mm
Infeed width 877 mm
Flywheel mass 1000 kg
Quick change blades 10 db
Chipping drum ⌀ 495 mm
Max. drive speed max 1000 km/h
Grates sizes optional
