ARX45-2

Dimensions

Machine length: 2915 mm
Wheelbase: 1950 mm
Machine height: 2840 mm
Machine height (folder rops): 2150 mm
Drum width: 1380 mm
Working width with offset: 1420 mm
Machine length (folded rops): 3000 mm
Ground clearance: 330 mm
Side clearance: 605 mm
Drum diameter: 850 mm
Drum shell thickness: 18 mm
Machine width (total): 1460 mm

Weight & operating characteristics

	ARX 45-2 light tandem vibratory roller (EU Stage V / U.S. EPA Tier 4 Final)	ARX 45-2 light tandem vibratory roller (EU Stage IIIA / U.S. EPA Tier 4 Interim)
Operating weight:	4395 kg	4405 kg
Operating weight max.:	4685 kg	4695 kg
Stat. lin. load of front drum:	15.5 kg/cm	15.5 kg/cm
Stat. lin. load of rear drum:	17.8 kg/cm	17.8 kg/cm
Turning radius inside:	2830 mm	2830 mm
Steering / oscillating angle:	35/9 ±°	35/9 ±°
Drum offset:	40 mm	40 mm

Engine

	ARX 45-2 light tandem vibratory roller (EU Stage V / U.S. EPA Tier 4 Final)	ARX 45-2 light tandem vibratory roller (EU Stage IIIA / U.S. EPA Tier 4 Interim)
Engine Type:	Kubota D1803-CR-T	Kubota V2403-M
Emission class:	EU Stage V / U.S. EPA Tier 4 Final	EU Stage IIIA / U.S. EPA Tier 4i
Power output ISO 3046:	32.8 kW (44 HP)	34.1 kW (45.7 HP)
Cylinder / ltr.:	3 cyl / 1826 cm³	4 cyl / 2434 cm³
Nominal speed:	2400 rpm	2400 rpm
Travel speed:	10 km/h	10 km/h
Gradeability with / without vibr.:	30 % / 40 %	30 % / 40 %

Compaction Forces

Amplitude I: 0.4 mm
Amplitude II: 0.6 mm
Frequency I: 41 Hz
Frequency II: 55 Hz
Centrifugal force I: 45 kN
Centrifugal force II: 56.4 kN
Centrifugal force III: 57.6 kN

Miscellaneous Forces

Battery / capacity: 12/77 V/Ah
Water tank: 340 l
Hydraulic tank: 53.5 l
Diesel fuel tank: 57 l
