Dimensions
- Machine length: 2500 mm
- Wheelbase: 1740 mm
- Machine height: 2550 mm
- Machine height (folder rops): 1935 mm
- Drum width: 1000 mm
- Working width with offset: 1040 mm
- Machine length (folded rops): 2585 mm
- Ground clearance: 280 mm
- Side clearance: 490 mm
- Drum diameter: 695 mm
- Drum shell thickness: 13 mm
- Machine width (total): 1130 mm
Weight & operating characteristics
- Operating weight: 2260 kg
- Operating weight max.: 2425 kg
- Stat. lin. load of front drum: 10.7 kg/cm
- Stat. lin. load of rear drum: 10,9 kg/cm
- Turning radius inside: 2630 mm
- Steering / oscillating angle: 30/6.5 ±°
- Drum offset: 40 mm
Engine
- Manufacturer: Kubota D1703-M-DI | Yanmar 3TNV88F-EPAMM
- Emission class: EU Stage V / U.S. EPA Tier 4 Final
- Power output ISO 3046: 18.5 kW (24.8 HP)
- Cylinder / ltr.: 3 cyl / 1826 cm³
- Nominal speed: 2100 / 2400 rpm
- Travel speed: 10 km/h
- Gradeability with / without vibr.: 25% / 30 %
Compaction Forces
- Amplitude I: 0.5 mm
- Amplitude II: 0.5 mm
- Frequency I: 58 Hz
- Frequency II: 66 Hz
- Centrifugal force I: 31.4 kN
- Centrifugal force II: 36.9 kN
Miscellaneous
- Battery / capacity: 12/77 V/Ah
- Water tank: 190 l
- Hydraulic tank: 28.5 l
- Diesel fuel tank: 35 l
