Dimensions

• Machine length: 4720 mm
• Wheelbase: 3500 mm
• Machine height: 3000 mm
• Drum width: 1680 mm
• Machine width: 1800 mm
• Side clearance: 780 mm
• Ground clearance: 300 mm
• Drum diameter: 1220 mm
• Drum shell thickness: 22 mm

Weight & operating characteristics ARX 110 & ARX 110 HF

• Operating weight: 10 340 kg
• Operating weight max.: 11 810 kg
• Stat. lin. load of front drum: 31.2 kg/cm
• Max. transport speed: 10.5 km/h
• Gradeability with/without vibration: 25% / 30%
• Turning radius inner (edge): 5470 mm
• Drum offset: 170 mm

Engine

• Manufacturer: Deutz TCD3.6 L4
• Power output ISO 14396: 74.4 kW (100 HP)
• Max. torque: 410/1600 Nm/rpm
• Emission class: EU Stage V / U.S. EPA Tier 4 Final
• Exhaust gas after-treatment: EGR+DOC+DPF+SCR
