Weight & operating characteristics ARP 95
- Operating weight CECE: 9930 kg
- Operating weight max.: 11 505 kg
- Stat. lin. load of front drum: 26.6 kg/cm
- Stat. lin. load of rear drum: 29.5 kg/cm
- Travel speed: 10 km/h
- Gradeability with vibration: 25%
- Gradeability without vibration: 30%
- Turning radius inner (edge): 3065 mm
- Turning radius outer (contour): 4785 mm
- Oscillation angle: ±6°
- Angle of steering: ±25°
Weight & operating characteristics ARP 95 (ACEpro)
- Operating weight CECE: 9970 kg
- Operating weight max.: 11 545 kg
- Stat. lin. load of front drum: 29.9 kg/cm
- Stat. lin. load of rear drum: 29.5 kg/cm
- Travel speed: 10 km/h
- Gradeability with vibration: 25%
- Gradeability without vibration: 30%
- Turning radius inner (edge): 3065 mm
- Turning radius outer (contour): 4785 mm
- Oscillation angle: ±6°
- Angle of steering: ±25°
Engine
- Manufacturer: Deutz TCD3.6 L4
- Power output ISO 14396: 74.4 kW (100 HP)
- Nominal speed: 2200 min-1 (RPM)
- Emission class: EU Stage V / U.S. EPA Tier 4 Final
- Exhaust gas after-treatment: EGR+DOC+DPF+SCR
Miscellaneous
- Drum offset: 1390 mm
- Max working offset mode: 3070 mm
- Brakes operating: Hydrostatic
- Brakes parking: Mechanical multiple-disc
- Brakes emergency: Mechanical multiple-disc
- Fuel tank capacity: 165 l
- DEF (Adblue) tank: 10 l
- Water tank capacity: 800 l
- Battery / capacity: 24 V / 2×55 AH
Compaction Forces ARP 95
- Frequency I: *38–42Hz
- Frequency II: *42–52 Hz
- Amplitude I: *0.65 mm
- Amplitude II: *0.28 mm
- Centrifugal force I: *74–91 kN
- Centrifugal force II: *39–60 kN
* Standard & ACEforce drum
Compaction Forces ARP 95 (ACEpro)
- Frequency I: 42 Hz
- Frequency II: 52 Hz
- Amplitude I: 0.65 mm
- Amplitude II: 0.28 mm
- Centrifugal force I: 91 kN
- Centrifugal force II: 60 kN
- Frequency ACEpro min: 37 Hz
- Frequency ACEpro max.: 52 Hz
- Amplitude ACEpro max.: 0.85 mm
- Centrif. force ACEpro max.: 110 kN
Maximum recommended compacted lift thickness at optimal working conditions
- Rockfill: N/A
- Sand / gravel: 400 mm
- Mixed soils: 300 mm
- Silt: N/A
- Clay: N/A
- Stabilisation: 200 mm
- Asphalt: 140 mm
