Dimensions

  • Machine length: 4100 mm
  • Wheelbase: 3000 mm
  • Machine height: 3000 mm
  • Drum width: 1500 mm
  • Machine width: 1670 mm
  • Curb clearance: 715 mm
  • Ground clearance: 240 mm
  • Drum diameter: 1100 mm
  • Drum thickness: 18 mm

Weight & driving characteristic

  • Operating weight CECE: 7375 kg
  • Stat. lin. load: 24.6 kg
  • Travel speed: 10 km/h
  • Oscillation angle: ± 6°
  • Steering angle: ± 24°
  • Turning radius, inner (edge): 2938 mm
  • Drum offset: 1220 mm

Engine

  • Manufacturer: Kubota V3307-CR-T
  • Power output ISO 14396: 54.4 kW (74 HP)
  • Emission class: EU Stage V, U.S. EPA Tier 4 Final
  • Exhaust gas after-treatment: EGR+DOC+DPF

Compaction forces

  • Frequency I: 38-48 Hz
  • Frequency II: 45-55 Hz
  • Amplitude I: 0,68 mm
  • Amplitude II: 0,39 mm
  • Centrifugal force I: 58-92 kN
  • Centrifugal force II: 47-70 kN

Miscellaneous

  • Fuel tank capacity: 180 liters
  • Water tank capacity: 900 liters

Maximum recommended compacted lift thickness at optimal working conditions

  • Rockfill: N/A
  • Sand / gravel: 350 mm
  • Mixed soils: 250 mm
  • Silt: N/A
  • Clay: N/A
  • Stabilisation: 180 mm
  • Asphalt: 40-130 mm
