Weight & dimensions
| APR 30/60 Petrol | APR 30/60 Diesel | |
|---|---|---|
| Machine weight | 199 kg | 215 kg |
| Machine weight (with options) | 214 kg | 243 kg |
| Base plate length | 330 mm | 330 mm |
| Machine length | 700 mm | 700 mm |
| With handle | 1140 mm | 1140 mm |
| Machine height | 765 mm | 785 mm |
| Handle height (work) | 1000 mm | 1000 mm |
| Handle height (transport) | 1180 mm | 1180 mm |
| Machine width | 500 mm | 500 mm |
Engine
| APR 30/60 Petrol | APR 30/60 Diesel | |
|---|---|---|
| Hand-arm vibrations | Honda GX 270 | Hatz 1 B 30 |
| Speed | Petrol | Diesel |
| Fuel tank | 6 kW / 8 HP | 4.5 kW / 6 HP |
| Gradeability | 3100 | 2900 |
| Max. incline to all sides | 2.1 l/h | 1.3 l/h |
Compaction forces
| APR 30/60 Petrol | APR 30/60 Diesel | |
|---|---|---|
| Max. vibration frequency | 90 Hz | 90 Hz |
| Max. centrifugal force | 32 kN | 32 kN |
| Working surface | 936 m²/h | 1044 m²/h |
| Spec. surface pressure | 16,2 N/cm² | 16,2 N/cm² |
| Amplitude | 1.2 mm | 1.2 mm |
Miscellaneous
| APR 30/60 Petrol | APR 30/60 Diesel | |
|---|---|---|
| Hand-arm vibrations | < 2.5m/sec² | < 2.5m/sec² |
| Speed | 26 m/min | 29 m/min |
| Fuel tank | 5.3 l | 5.0 l |
| Gradeability | 35% | 35% |
| Max. incline to all sides | 20° | 20° |
