Weight & dimensions
APR 30/50 Petrol | APR 30/50 Diesel | |
---|---|---|
Machine weight | 199 kg | 215 kg |
Machine weight (with options) | 214 kg | 243 kg |
Base plate length | 330 mm | 330 mm |
Machine length | 700 mm | 700 mm |
With handle | 1140 mm | 1140 mm |
Machine height | 765 mm | 785 mm |
Handle height (work) | 1000 mm | 1000 mm |
Handle height (transport) | 1180 mm | 1180 mm |
Machine width | 500 mm | 500 mm |
Engine
APR 30/50 Petrol | APR 30/50 Diesel | |
---|---|---|
Hand-arm vibrations | Honda GX 270 | Hatz 1 B 30 |
Speed | Petrol | Diesel |
Fuel tank | 6 kW / 8 HP | 4.5 kW / 6 HP |
Gradeability | 3100 | 2900 |
Max. incline to all sides | 2.1 l/h | 1.3 l/h |
Compaction forces
APR 30/50 Petrol | APR 30/50 Diesel | |
---|---|---|
Max. vibration frequency | 90 Hz | 90 Hz |
Max. centrifugal force | 32 kN | 32 kN |
Working surface | 780 m²/h | 870 m²/h |
Spec. surface pressure | 19,4 N/cm² | 19,4 N/cm² |
Amplitude | 1.2 mm | 1.2 mm |
Miscellaneous
APR 30/50 Petrol | APR 30/50 Diesel | |
---|---|---|
Hand-arm vibrations | < 2.5m/sec² | < 2.5m/sec² |
Speed | 26 m/min | 29 m/min |
Fuel tank | 5.3 l | 5.0 l |
Gradeability | 35% | 35% |
Max. incline to all sides | 20° | 20° |
