Weight & dimensions

• Machine weight: 135 kg
• Machine weight (with options): 146 kg
• Base plate length: 330 mm
• Machine length: 700 mm
• With handle: 1140 mm
• Machine height: 755 mm
• Handle height (work): 1000 mm
• Handle height (transport): 1180 mm
• Machine width: 380 mm

Engine

• Engine: Hatz 1B20
• Fuel: Diesel
• Engine output: 3.1 kW / 4.2 HP
• at RPM: 3000
• Fuel consumption: 0.9 l/h

Compaction forces

• Max. vibration frequency: 95 Hz
• Max. centrifugal force: 25 kN
• Working surface: 479 m²/h
• Spec. surface pressure: 19,9 N/cm²
• Amplitude: 1.5 mm

Miscellaneous

• Hand-arm vibrations: < 2.5m/sec²
• Speed: 21 m/min
• Fuel tank: 3.0 l
• Gradeability: 35%
• Max. incline to all sides: 30°
• Water tank: 9.4 l
