Dimensions & weights

  • Machine weight: 84/(1) 88 kg
  • Machine weight (incl. optional sprinkler & wheels): 93/(1) 97 kg
  • Machine length: 700 mm
  • Machine lenght with handle: 1020 mm
  • Base plate length: 559 mm
  • Ground contact length: 352 mm
  • Machine height: 667 mm
  • With handle (work): 976 mm
  • With handle (transport): (2)736 /(3)960 mm
  • Machine width: 500 mm

(1)Vanguard & Rato
(2)Honda & Rato
(3)Vanguard

Compaction forces

  • Max. vibration frequency: 100 Hz
  • Max. centrifugal force: 15 kN
  • Working surface: 720 m²/h
  • Spec. surface pressure: 8.5 N/cm²

Engine

  Honda GX 120 Vanguard 160 Rato R180
Fuel Petrol Petrol Petrol
Engine output 2.6 kW (3.5 HP) 3.7 kW (5 HP) 3.8 kW (5.1 HP)
AT RPM 3600 3600 3600

Miscellaneous

  • Hand-arm vibration on handle: <2.5 m/s²
  • Speed: 0–24 m/min
  • Gradeability: 30 %
  • Max. Incline to all sides: 20 °

Options

  • Rubber mat: X
  • Transport wheels: X
  • Water sprinkler system: 12 l
